DINIC DisplayPort 1.2 connector, 4K 60Hz, black, DINIC box with Euro-hole

Mobile Preview: DINIC DisplayPort 1.2 connector, 4K 60Hz, black, DINIC box with Euro-hole

Mobile Preview: DINIC DisplayPort 1.2 Connector, 4K60Hz black,

DINIC DisplayPort 1.2 connector, 4K 60Hz, black, DINIC box with Euro-hole

Product No.:: DP-BU-KB
Shipping time:: Immediately
Stock:: 25 pieces
Packaging::: DINIC box
Warennummer:
EAN:: 4032528041346
Weight:: 0.03 kg per piece

3,49 EUR

plus 19% tax

Quantity

Description

Description

DINIC DisplayPort 1.2 Connector, Female/Female, 4K 60Hz, black

Passive DisplayPort connector for connecting two standard DisplayPort cables.

Connections:
DisplayPort female ↔ DisplayPort female

DisplayPort:
Version 1.2, backwards compatible with 1.1

Resolution:
Up to 4K (3840 × 2160) @ 60 Hz

Bandwidth:
Up to 21.6 Gbit/s (HBR2)

Item number:
DP-BU-KB

EAN:
4032528041346

Advantages

1:1 connection of two DisplayPort cables without active signal amplification
Up to 4K (3840 × 2160) at 60 Hz
Up to 21.6 Gbit/s bandwidth in accordance with HBR2
Supports MST, Adaptive-Sync, 3D and HDCP 1.3
Bidirectional signal transmission with no specified connection orientation
Gold-plated pins for corrosion-resistant contact

Product description

The DINIC DisplayPort 1.2 connector, featuring a DisplayPort female to DisplayPort female configuration, connects two standard DisplayPort cables to form a continuous connection. The passive adapter transmits the signal 1:1 and operates without active signal amplification.

It supports a bandwidth of up to 21.6 Gbit/s via HBR2, as well as resolutions up to 4K (3840 × 2160) at 60 Hz. In addition, resolutions of up to 2560 × 1440 at 165 Hz are possible, depending on the system. MST, Adaptive-Sync, 3D and HDCP 1.3 are supported. The signal transmission is bidirectional. The black housing is made of PVC/ABS, and the pins are gold-plated.

Applications

Workstation cabling between a PC, workstation and monitor
Connections to docking stations as well as KVM and AV systems
Routing and extending existing DisplayPort runs in IT and server cabinets
Display and projector connections in conference and training rooms
Digital video connections for HMI and panel PC applications

Technical specifications

Brand

DINIC

Item number

DP-BU-KB

EAN

4032528041346

Product type

DisplayPort connector / coupler

Connections

1× DisplayPort socket ↔ 1× DisplayPort socket

DisplayPort version

1.2, backwards compatible with 1.1

Max. bandwidth

21.6 Gbit/s (HBR2)

Max. resolution

Up to 4K (3840 × 2160) @ 60 Hz; up to 2560 × 1440 @ 165 Hz, depending on the system

Supported features

MST, Adaptive-Sync, 3D, HDCP 1.3, HBR2

Signal direction

Bidirectional

Contact surface

Gold-plated pins

Housing material

PVC / ABS

Colour

Black

Packaging

DINIC box with Euro-hole

Weight

Approx. 0.03 kg per item

Compatibility

Suitable for connecting two cables with standard DisplayPort connectors in DisplayPort 1.2 environments. Typical connections include, for example, those between a graphics card, workstation or docking station and a monitor, display or projector. DisplayPort 1.2 is backwards compatible with DisplayPort 1.1.

Practical note on cable length

The connector operates passively and does not amplify the DisplayPort signal. For longer combined lengths of the two connected cables, the achievable bandwidth and resolution may depend on the cable quality, the graphics output and the connected device.
