Technical highlights

• Optical Toslink digital cable, Toslink plug on both ends (standard S/PDIF)
• Cable length: 5.0 m, round cable with an outer diameter of approx. 4 mm
• Cable and plug colour: white - discreet integration in bright environments
• HQ plug in DINIC Monaco Range design for precise, dimensionally stable plug connection
• Optical transmission, insensitive to electrical and magnetic interference
• Slim cable design for easy installation in cable ducts and AV racks
• Packaging: DINIC box with Euro hole - suitable for shelf and counter presentation in specialist stores

Cable description

The DINIC Toslink cable from the Monaco range is an optical digital cable for professional audio applications in AV and media technology environments. Digital audio signals are transmitted by light waves via the optical S/PDIF interface, which means that the signal remains largely insensitive to electrical and magnetic interference fields - an advantage particularly in installations with a high line density.

The slim round cable design with an outer diameter of approx. 4 mm facilitates installation in cable ducts, rails and narrow AV racks. The white design of the cable and connectors blends unobtrusively into light-coloured environments, for example in modern conference or training rooms, showrooms or residential properties that are equipped by specialist companies.

The HQ plugs in the Monaco Range design ensure a defined guide in the socket and a mechanically robust connection. In combination with the 5 m length, the cable is suitable for typical distances between the signal source and audio peripherals in permanently installed or semi-stationary systems.

Areas of application

• Connection of set-top boxes, receivers and TV sets with AV receivers or audio processors
• Soundbars, active loudspeaker systems and DACs with optical S/PDIF input
• Media technology in conference, training and meeting rooms
• AV racks in companies, educational institutions and hospitality environments
• System integration in the field of presentation and sound reinforcement technology

Technical data

Characteristic	Value
Item number	MO-TTA-5WKB
Cable type	Optical Toslink digital cable (S/PDIF)
Connector types	Toslink plug - Toslink plug
Cable length	5,00 m
Outer diameter of cable	approx. 4 mm (round cable)
Colour cable / plug	white / white
Series	DINIC Monaco Range, HQ plug design
Signal transmission	Digital, optical (S/PDIF, Toslink)
Packaging	DINIC box with Euro hole
EAN	4032528042602
Weight (approx.)	0.132 kg per piece

Compatibility

Suitable for devices with an optical S/PDIF/Toslink connection (e.g. according to IEC 60958-3), among others:

• AV receivers, surround decoders, DACs
• Set-top boxes, SAT and cable receivers
• TV sets, media players, streaming boxes
• Soundbars and active speaker systems with Toslink input

Scope of delivery

1 x DINIC Toslink cable, 4mm Ø, white, length 5.00 m, in DINIC box with Euro hole.
