DINIC twist-on F-connector for cable 7.3mm, quantity: 100 pieces, DINIC polybag, length 20mm
DINIC twist-on F-connector for cable 7.3mm, quantity: 100 pieces, DINIC polybag, length 20mm
DINIC twist-on F connector CU, 7.3 mm - 20 mm, polybag (100 pieces)
F screw-on connector (screw mounting) for SAT/coax cables up to Ø 7.3 mm, nickel-plated copper, wide nut.
Technical highlights
- Plug type: F plug (screw-on version) for SAT/coaxial applications
- Suitable for cable outer diameter: max. 7.3 mm
- Plug length: 20 mm
- Material: Copper, nickel-plated (corrosion-reduced surface)
- Special feature: large/wide nut for secure screw connection and easy handling
- Assembly: Screw onto stripped coaxial cable - quick assembly without crimping pliers
- Packaging unit: 100 pieces in DINIC polybag
Product description
The DINIC twist-on F connector is designed for fast, practical assembly of SAT/coaxial cables. The twist-on design is screwed onto the prepared coaxial cable and thus enables rapid assembly during installation and service.
The nickel-plated copper body supports a durable, easy-to-install connection. The large, wide nut facilitates secure tightening on F interfaces and is advantageous for frequent connection changes and in environments with limited accessibility.
Areas of application
- SAT and BK distributions in building technology (installation, expansion, maintenance)
- System integration and service operations (replacement/reassembly of coax cables)
- Headend and multi-switch environments
- Specialised trade/project business: stock packs for ongoing installations
Technical data
| Product type |
Twist-on F-connector (SAT/coax) |
| Connection / mounting |
Screw-on mounting (screw mounting on coax cable) |
| Cable outer diameter |
max. 7.3 mm |
| Plug length |
20 mm |
| material |
Copper, nickel-plated |
| Design |
Large/wide nut |
| Colour |
Metallic (nickel) |
| Packaging |
DINIC Polybag |
| Quantity (PU) |
100 pieces |
| Item number |
SAT-ST-73-100 |
| EAN CODE |
4032528034522 |
| Weight (PU) |
approx. 0.4 kg |
Compatibility
Suitable for SAT/coax cables with an outer diameter of up to Ø 7.3 mm. For connections to components with an F interface (screw thread), e.g. LNBs, multiswitches, SAT receivers, SAT/BK distributors and aerial/SAT sockets with an F connection.
Notes
Use only under direct adult supervision
Scope of delivery
- 100x DINIC twist-on F-plugs, suitable for cables up to Ø 7.3 mm
- Packed in DINIC polybag
DINIC is a trademark of MAG GmbH.
Keywords: DINIC twist-on F-connector, F-connector SAT, coaxial accessories, 7.3 mm, 20 mm, nickel-plated copper, polybag 100 pieces
Manufacturer:
MAG GmbH
Vechelder Str. 22
38268 Lengede
Email: dinic@mag.de
Safety Information:
Use only under direct adult supervision
