Technical highlights

• Simplex OS2 singlemode fibre optic for point-to-point connections
• LC/APC 8° connector on both ends for low-loss singlemode connections
• Length 50 m, compact cable outer diameter 2.0 mm for flexible installation over longer distances
• LSZH jacket (Low Smoke Zero Halogen) for increased safety in buildings and technical rooms
• White colour - unobtrusive routing along walls, skirting boards and in racks
• Designed for fibre optic router/ONT connection in FTTH/FTTB environment

Description

The connection cable connects fibre optic routers, ONTs or media converters to the existing LC/APC interface in the FTTH/FTTB network. It is a simplex OS2 singlemode cable with LC/APC 8° connectors on both ends, designed for high-performance point-to-point data connections on singlemode infrastructures.

The 2.0 mm round cable construction enables space-saving and easy routing in patch panels, house distributors and router environments. The LSZH (Low Smoke Zero Halogen) jacket reduces the development of smoke and harmful gases in the event of a fire, which supports use in areas with increased safety requirements, such as office buildings, technical rooms and IT infrastructures.

The 50 m length is designed for connections over longer distances within buildings, e.g. between the building transfer point and the central plant room, between floor distributors or to remote workstations. The route can be realised continuously without additional couplings or splices, which supports signal integrity and fault management in professional installations. The white jacket colour facilitates visually neutral integration into existing installations.

Areas of application

• FTTH/FTTB connection of fibre optic routers and ONT/CPE
• Connections between fibre optic transfer point and end device in the building distributor or technical room
• In-building fibre optic connections over longer distances, e.g. between floors or remote rooms
• Patching in 19" distribution panels and fibre optic panels with LC/APC interfaces
• System integration in telecommunication and IT infrastructures
• Network modernisation from copper to fibre optic connections in professional environments

Technical data

Article description	Connection cable for fibre optic router, simplex OS2, LC/APC 8° to LC/APC 8°, 50 m, LSZH, white
Article number	LWR-LCA-LCA-50
Cable type	Simplex singlemode fibre optic OS2
Connector type side A	LC/APC 8°
Connector type side B	LC/APC 8°
Polishing	APC, 8° angle polish (both sides)
length	50 m
Outer diameter	2.0 mm round cable
Sheath material	LSZH (Low Smoke Zero Halogen)
Sheath colour	White colour
Category	Fibre optic connection router / Fibre optic connection cable
Manufacturer / Brand	DINIC / MAG GmbH

Compatibility

Suitable for devices and connection points with LC/APC single-mode socket (OS2), e.g. fibre optic routers, ONT/CPE, media converters, fibre optic patch panels and LC/APC couplers in FTTH/FTTB and professional network environments.

Scope of delivery

1 x connection cable for fibre optic router, Simplex OS2, LC/APC 8° to LC/APC 8°, 50 m, LSZH, white.
